EUROTEC Connections | T PROFILE Connector 115mm x 2000mm x 80mm in Aluminium

T-profile Hidden Aluminium Connector

Eurotec's T-profile is a high-quality aluminium connector designed for hidden installations in both indoor and outdoor wood projects. Ideal for right-angled and inclined connections, this T-profile is suitable for wood, wood-concrete, and concrete-wood applications. With a self-drilling EST rod dowel and rock concrete screw, installation is simple and efficient. The T-profile is available in a 2.00 m length and can be custom cut on-site with a measurement scale. This product is suitable for service classes 1 and 2 according to DIN EN 1995 – Eurocode 5.

Product Uses

  • Hidden connections in wood and wood-concrete applications
  • Right-angled and inclined beam connections
  • Indoor and outdoor installations

Technical Data

  • Dimensions: 115 x 2000 x 80 mm
  • Material: High-quality aluminium
  • Service classes: 1 and 2 (DIN EN 1995 – Eurocode 5)
  • Length: 2.00 m
  • Self-drilling EST rod dowel (Ø 7.5)
  • Rock concrete screw (Ø 7.5) for wood-concrete joints
  • Measurement scale for on-site cutting

Instructions for use

  1. No need for pre-drilling with the self-drilling EST rod dowel (Ø 7.5)
  2. Hole pattern for the 5.0 x 50 mm angle-bracket screw
  3. Rock concrete screw (Ø 7.5) for the wood / concrete joint

Product Data Sheet

T-Tec System

Art. no. Designation Dimensions (H x L x W) Material Material thickness PU EAN
975652
T-Profil
115 x 2000 x 80 mm
Aluminium
6 mm
1 Pieces
4251314730206
